DX-1450/1650/1650XL/2050/2100 Auto High-speed Flute Laminator

Product : Auto High-speed Flute Laminator Model: DX-1450/1650/1650XL/2050/2100
Availability:
Inquire

Description


Main Features


  • This Auto High-speed Flute Laminator is capable to laminate and glue combination of corrugated board and any type of upper paper or board together. After shearing or mold cutting, the laminated products can be made to be carton case, box and related products.



Specification

Model/Modelo

DX-1450


DX-1650


DX-1650XL


DX-2050

DX-2100

Max. SheetSize(WXL)

Tamaño máximo (WXL)

1450mmx1450mm

(57’x57’)

1650mmx1450mm

(65’x57’)

1650mmx1650mm

(65’x65’)

2050mmx1650mm

(817’x65’)

2100mmx2100mm

(83x83’)

Min. Sheet Size(WXL)

Tamaño mínimo de tabla

400mmx400mm

(16’x16’)


400mmx400mm

(16’x16’)



400mmx400mm

(16’x16’)


550mmx450mm

(21’x18’)

550mm*450mm

(22x18’)

Thickness of Upper Paper

Grosor del papel

120~600gsm



Thickness of Bottom Paper

Grosor de fondo

0.5-10mm

A-N Flute single layer/3 layers/5 layers /7 layers Corrugate board, Grey Board and Board

Flauta A-N de una capa / 3 capas / 5 capas / 7 capas Tablero corrugado, tablero gris y tablero

Max. Speed

Velocidad máxima

150m/min (Subject to board quality and specification)

Laminating Precision

Precisión de laminado

±1.5mm

±1.5mm±1.5mm±1.5mm

±2mm

Power

Poder


200V/-380V3-25HP



200V/-380V3-25HP



200V/-380V3-25HP


200V/-380V3-25HP

200V/-380V3-25HP
